Tea Pouch Packing Machine Manufacturer in Ahmedabad
Acuapuro Water Equipment is a leading “Automatic Tea Pouch Packing Machine, Tea Mix Packing Machine” Manufacturer and Supplier From Ahmedabad, Gujarat, India.
This system is capable of accurately handling packing weighing between 50 g and 1 kilogram without the need to swap out any elements. Additionally, these devices offer assistance in the packaging of pouches, cartons, and jars.
An innovative photoelectric sensor tracking system, an independent digital temperature controller for horizontal/vertical sealing, a proprietary rotating head based on nano power technology, taking up less floor space, and providing sanitary packaging support are just a few of its characteristics.
A major portion of our machines is exported to our clients in countries of African Countries, USA, Gulf Countries, and Neighbour of India Country as well.
Specifications
- FEEDING HEAD: Auger Screw Feeding System
- PACKING RANGE: 10gms to 25gms
- PRODUCTION SPEED: 30 to 40 Pouches / min
- MACHINE CONTROL SYSTEM: V.F.D
- FILM WIDTH: up to 250mm
- FILM THICKNESS: 50 to 100 microns
- FILM MATERIAL: Any laminated films
- SEALER HEATING SYSTEM: Continue Sealing System
- FILLING ACCURACY: +/- 1%
- INNER CORE DIA. OF FILM ROLL: 70mm
- OUTER DIA. OF THE FILM ROLL: up to 300mm
- POUCH STYLE: Side Seal type
- POUCH WIDTH: up to 100mm
- POUCH LENGTH: up to 145mm
- COMPRESSED AIR PRESSURE: N/A
- AIR CONSUMPTION: N/A
- POWER CONSUMPTION: 3KW / Hour
- PEAK POWER: 3kW
- POWER REQUIREMENT: 5KVA, 3Phase
- FILM GUARD MECHANISM: N/A
- POUCH COUNTER: Provided
- DATE PRINTING DEVICE: Optional
- PHOTO CELL: Inclusive
- MACHINE DIMENSIONS IN ‘MM’: H1850xW1000x D1000
- NET WEIGHT : 450 kgs
We have an in-house manufacturing facility for almost all Pouch Packing Machinery like Mineral Water Packing Machines, Juice Pouch Packing Machines, Masala / Spice Packing Machines, contact us at +91-9737344555 or mail us at info@acuapuro.com. Acuapuro Water will provide the Turnkey Solution for the Packaged Drinking Water Plant.
